The galvanising pot is the core equipment in the hot-dip galvanising process, serving as the vessel that holds molten zinc solution. It enables metal workpieces to acquire a zinc coating by immersion in the zinc bath. The following provides a detailed introduction:
Working Principle: The Zinc Pot operates through the hot-dip galvanising process, immersing steel materials into molten zinc to form a protective zinc coating on their surfaces. This provides corrosion resistance and decorative benefits.
Material Types
Iron Zinc Pots: Typically constructed from low-carbon steel such as AGXG08 or specialised boiler steel, featuring a corrosion-resistant alloy layer. They feature low initial investment, high heating efficiency, and ease of maintenance. However, their service life is relatively short, typically 2 to 5 years, and they carry safety risks associated with molten zinc leakage.
Ceramic zinc pot: More accurately termed a refractory zinc pot, its core consists of a pot body constructed from special refractory materials such as silicon carbide. They boast exceptionally long lifespans exceeding 10 years, minimal zinc consumption and slag production, and high safety reliability. However, they entail high initial investment, slow heating rates, and challenging maintenance.
Other Material Zinc Pots: Options include stainless steel, alloy steel, and titanium alloy zinc pots. Stainless steel pots offer strong corrosion resistance and longevity, suitable for large-scale production lines; Alloy steel zinc pots withstand high temperatures and possess high strength, making them suitable for production lines with stringent temperature control requirements; titanium alloy zinc pots offer corrosion resistance and high-temperature tolerance, but come with extremely high costs and significant processing difficulties, thus being predominantly used in high-end galvanising equipment.
Heating Methods
External Heating: Iron zinc pots commonly employ external heating methods such as gas open-flame heating or electric radiant tube heating, which directly heat the pot walls, resulting in relatively high thermal conduction efficiency.
Internal Heating: Ceramic zinc pots predominantly employ internal heating, where electric heaters or gas burners are immersed directly into the molten zinc, achieving thermal efficiency exceeding 90%.
Dimension Specifications: Zinc pot dimensions must be determined based on workpiece size and production process. The effective length requires a safety margin of 0.5 to 1.5 metres beyond the maximum workpiece length; The effective width must incorporate a safety margin of 0.3 to 0.8 metres beyond the maximum workpiece width or lifting equipment width. Effective depth must account for the maximum workpiece height, zinc immersion depth, dross zone height, and safety margin for liquid level fluctuations.
Application Fields: Galvanising pots are extensively employed across automotive, construction, household appliances, chemical, mechanical, petroleum, metallurgical, light industry, transportation, power generation, aerospace, and marine engineering sectors. They facilitate hot-dip galvanising of metallic materials including steel plates, steel strips, steel wire, and steel pipes.
Selecting the appropriate Zinc Pot requires focusing on core production requirements such as workpiece characteristics, production capacity, and budget constraints. Key parameters including material, dimensions, and heating method must be considered, whilst accommodating external limitations such as workshop conditions. The following outlines specific selection methods:
Define Core Direction Based on Workpiece Characteristics
Workpiece Specifications and Weight: For processing small precision components such as bolts and hardware fittings, ceramic zinc pots are preferable. Their uniform zinc bath temperature minimises workpiece deformation and produces a fine coating finish. For heavy-duty items like steel structural beams and large pipes, iron zinc pots are suitable. They offer flexible sizing options and avoid the risk of ceramic pots sustaining damage from impacts.
Workpiece Quality Requirements: For components used in demanding environments like marine or power generation applications, where high corrosion resistance and coating uniformity are essential, ceramic zinc pots minimise zinc dross contamination, stabilise bath composition, and enhance coating quality. For standard building components with less stringent galvanising requirements, carbon steel zinc pots adequately meet basic needs.
Selecting Specifications and Types Based on Production Scale
Large-scale continuous production: For bulk orders like steel structures or transmission towers at major galvanising plants, opt for large-capacity ceramic or stainless steel zinc pots. These offer extended service life and high thermal efficiency, minimising downtime for maintenance. For instance, large-volume ceramic pots maintain stable zinc bath temperatures, accommodating high daily throughput requirements.
Intermittent production for small-to-medium operations: For small workshops or start-ups with sporadic batches and low output, Low-carbon steel zinc pots represent a pragmatic choice. They feature low initial investment, straightforward maintenance, and can be rapidly welded if damaged, avoiding the substantial upfront costs of ceramic pots.
Balancing Investment and Operational Costs
Controlling Initial Costs: Where budgets are constrained and no immediate expansion plans exist, prioritise carbon steel or cast iron zinc pots. These offer low manufacturing costs and rapid production deployment to recoup investment, though operational expenses like zinc consumption and maintenance should be factored in.
Prioritise long-term benefits: For sustained energy savings and reduced consumption, consider ceramic or stainless steel zinc pots. Ceramic pots, though more expensive upfront, boast a lifespan exceeding 10 years and reduce zinc consumption by 5%-15%, yielding significant long-term savings. Stainless steel pots offer superior corrosion resistance and lower maintenance costs.
Matching Heating Methods to Production Processes
External Heating: Commonly used with gas flames or electric radiant tube heating, typically paired with iron zinc pots. This method offers rapid temperature rise, suitable for intermittent production requiring frequent start-stop cycles. However, it incurs significant heat loss and relatively high energy consumption.
Internal heating: Commonly found in ceramic zinc pots, where the heater is immersed directly into the zinc bath. This achieves thermal efficiency exceeding 85% and ensures uniform bath temperature, making it suitable for continuous production requiring high temperature precision, such as galvanising automotive components or precision hardware.
Determining zinc pot dimensions based on workshop conditions
Zinc pot dimensions must accommodate both production requirements and workshop constraints. On one hand, calculations should be based on workpiece dimensions, e.g., effective pot length = maximum workpiece length + 0.5–1.5 metres safety margin. Effective depth must account for immersion depth, slag zone, and liquid fluctuation space. On the other hand, consider workshop pit depth and crane clearance to prevent installation failures or workpiece handling issues. Additionally, 30mm-thick zinc pots may be selected for small-scale production lines, whilst 60mm thickness is recommended for extra-large pots exceeding 3m in depth. Pots deeper than 2m require external reinforcement with pot-supporting rods.
